RETİNA
AMBALAJLAR İÇİN ÖZEL BASKI MAKİNESİ
RETİNA
| Model | RETINA | Print Head | EPSON Industrial ALL-MEMS 8 Print Head |
| Printing Resolution | 360*600DPI | Max. Print Speed | 500 m2/h |
| Ink type and color | CMYK Water Based Ink | Picture Format | Tiff, Jpg, Pdf, Png |
| Max. Printing Width | 2480 mm | Media Thickness | 1-20 mm |
| Min. Feeding Width | 350*450 mm, 350*660 mm 350*450 mm, 350*660 mm |
Max. Feeding Width | 2500 mm |
| Feeding Mode | Auto Feeding | RIP Software | Maintop |
| Working Environment | 18~30⁰C, Humidity: 50%~70% | Operating System | Windows 7 or Later Version |
| Total Power | 8,5 KW | Electric Voltage | 380V±10% 50/60 Hz |
| Printer Weight | 2500 kg | Printer Size | 4420*3140*1720 mm |
General Informations;
- High-Performance Printheads
Equipped with Epson’s industry-leading PrecisionCore MicroTFP printheads, delivering exceptional print quality. Achieves a maximum printing speed of up to 500 m²/h, ensuring high efficiency for industrial applications.
- Advanced Belt-Driven Suction System
The industrial belt-driven suction system ensures seamless material movement, providing flawless printing on both small and large-sized cardboards with precision and consistency.
- Fully Automated Feeding System
Features a one-touch digital control for a fully automated feeding mechanism, significantly improving efficiency and accuracy while reducing manual operation time.
- User-Friendly Operation & Intelligent Monitoring
Designed for ease of use, the printer includes a three-color indicator light system for real-time status monitoring. Its sleek, industrial-grade design enhances both functionality and aesthetics.
